DERAILLEUR GEAR SYSTEM
Derailleur or "D" refers to an external shifting mechanism. It consists of a chain, multiple precision sprockets and a derailleur to "derail" the chain from one sprocket to another. It allows for quick transitions and more gearing options. Just remember to pedal while shifting and you're good to go!
EQUIPPED
Equipped, or "EQ" as we say at Electra, simply means your ride comes with some sweet added benefits. Color-matched fenders keep you clean and dry while front and rear LED lights help you see and be seen.
FLAT FOOT TECHNOLOGY
You really need to ride an Electra bike to feel the magic of Flat Foot Technology, but overall the benefits are comfort and control. It provides an upright, relaxed riding position with proper leg extension that allows you to plant your feet flat on the ground whenever you want or need to.
| Frame | 6061-T6 Aluminum with Flat Foot Technology® |
| Fork | High-tensile steel unicrown, straight/tapered leg |
| Tire | Electra custom 24x1.95'' w/reflective stripe |
| Hub Front | Shimano Nexus Dynamo, 32h // Shimano Nexus Dynamo, 32h |
| Hub Rear | Alloy low flange 32h w/QR |
| Rim | Anodized double-wall alloy 24''x32h w/machined sidewalls |
| Spokes | 14g stainless steel |
| Shifter | Shimano Tourney Revo 7-speed twist with optical gear display |
| Rear Derailleur | Shimano Tourney TY300 |
| Crank | Forged alloy 170mm w/steel 44t chainring w/double chainguards |
| Bottom Bracket | Square taper, loose ball |
| Cassette | 14-34, 7 speed freewheel |
| Chain | KMC Z7, 7 speed |
| Brake | Alloy linear pull |
| Brake Lever | Alloy, 3-finger |
| Pedal | Resin platform, non-slip tread |
| Saddle | Ergonomic w/shock-absorbing elastomers |
| Seatpost | Alloy 27.2x300mm |
| Handlebar | Alloy custom bend 25.9'' width/4'' rise |
| Stem | Forged alloy 25.4mm quill, 80mm extension |
| Headset | 1 1/8'' steel threaded/semi-integrated |
| Grips | Electra hand-stitched |
| Light | Spanninga, dynamo hub powered, LED, taillight // Light Front, Spanninga Kendo XD, LED |
| Kickstand | Alloy |
Geometry Chart
| Frame Reach | 31 |
| Frame Size Number | 24 |
| Frame Stack | 55.8 |
| Head Angle | 69.0° |
| Head Tube Length | 20 |
| Seat Tube | 42.1 |
| Seat Tube Angle | 67.0° |
| Standover | 46.7 |
| Wheelbase | 111.4 |
| Wheel Size | 24" kids' |
| Color | PEWTER |
| Size | 24" WHEEL |
