Trek madone slr 8 axs gen 8

Madone SLR 8 AXS Gen 8 is an ultra-aero, featherlight road bike thats built to race. Its 900 Series OCLV Carbon frame is not only aerodynamic, but also ultra-light for flying up climbs. Lightweight IsoFlow frame technology means that Madone doesnt sacrifice comfort for speed. To give you every aero advantage, Madone SLR comes with RSL Aero Bottles and Cages that further reduce drag. This build comes with a previous generation SRAM RED AXS drivetrain with a power meter, carbon wheels, and a Trek Aero RSL one-piece carbon bar/stem.

• Revolutionary Full System Foil aero tube shapes redefine what fast looks like and help optimize aerodynamics around the whole bike
• Its crafted from our highest-level 900 Series OCLV carbon thats mind-bogglingly light, stiff where you need the power, and compliant where you crave comfort
• Carbon wheels keep weight down and performance up, so you can crush climbs and soar down descents
• The previous generation SRAM RED AXS shifting is smooth, lighting-quick, and fully programmable, so you can tune your drivetrain to work exactly how you want it
• RSL Aero Bottles and Cages make the whole rider system faster to give you even more aerodynamic gains

Our lightest Madone Disc ever

New light and fast aero tube shaping paired with our best 900 Series OCLV Carbon makes Gen 8 our lightest Madone Disc f/s ever and as light as the Émonda f/s.

Redefines what fast looks like

Revolutionary new Full System Foil aero tube shapes improve airflow over the whole bike while maintaining the lightness climbers crave. Plus, the bike’s entire rider system was meticulously designed and rigorously tested to be faster everywhere.



80% more vertically compliant IsoFlow

We refined our race-focused comfort tech to be lighter and have nearly double the vertical compliance so you can ride stronger longer.

Designed for the world’s best

Madone SLR Gen 8 is raced and loved by Lidl-Treks fastest sprinters and climbers and the only bike they need for race day.

One-piece Aero RSL bar/stem

A new one-piece bar/stem is lighter, more aeryodynamic, and more ergonomic than the previous version. Plus, the hoods are 3cm narrower than the drops so you can adjust your positioning to prioritize aerodynamics (in the hoods) or power (in the drops).

RSL Aero Bottles and Cages

Included RSL Aero Bottles and Cages were specifically designed along with the whole rider system to help make Madone even faster.

Frame	900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
Fork	Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Wheel Front	Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle /
Wheel Rear	Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, SRAM XD-R driver, 142x12mm thru axle
Tire	Bontrager Aeolus RSL RD, Tubeless Ready, cotton construction, aramid bead, 170 tpi, 700x28mm // Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x28mm
Tire Part	Bontrager TLR sealant, 6oz
Skewer Front	Bontrager Switch chamfered thru axle, removable lever
Skewer Rear	Bontrager Switch chamfered thru axle, removable lever
Shifter	SRAM RED eTap AXS, 12 speed // SRAM RED eTap AXS, 12 speed
Front Derailleur	SRAM RED eTap AXS, braze-on
Rear Derailleur	SRAM RED eTap AXS, 36T max cog
Crank	SRAM RED AXS w/ power meter, 48/35, DUB, 165mm length
Bottom Bracket	SRAM DUB, T47 threaded, internal bearing
Cassette	SRAM XG-1290, 10-33, 12 speed
Chain	SRAM RED D1, 12 speed
Brake Rotor	SRAM CenterLine X, centerlock, round edge, 160mm
Saddle	Bontrager Aeolus P2 Pro, carbon rails, 155mm width
Seatpost	Madone aero carbon seatpost, 0mm offset, short length
Handlebar	Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 35cm control width, 38cm drop width, 80mm stem length
Battery	SRAM eTap battery pack (with charger)

Geometry Chart
